XFFR-15X4
Cable Accessories Heat Shrinkable Tubing Polyolefin Black Individual
廠商型號:
XFFR-15X4
芯天下內部編號:
35-XFFR-15X4
生產廠商:
te connectivity / raychem wire
描述:
Cable Accessories Heat Shrinkable Tubing Polyolefin Black Individual
產品類別:
Interconnect|Cable Accessories
客戶編號:
規格書:
查看PDF
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Type | Heat Shrinkable Tubing |
| Standard Package | Bulk |
| RoHS | RoHS Compliant |
| Material | Polyolefin (PO) |
| Color | Black |
| Minimum Shrink Temperature | + 70 C |
| Recovered Diameter | 12.7 mm |
| Length | 4 ft |
| Inside Diameter | 38.1 mm |
| Shrink Ratio | 3:1 |
| Chemical Resistant | Yes |
| Maximum Temperature | + 110 C |
| Operating Temperature Range | - 55 C to + 110 C |
| Series | XFFR |
| Part # Aliases | CB5440-000 |
| 顏色 | 黑色 |
| 襯有膠粘劑 | 否 |
| 套管直徑 | 38.1mm |
| 套管類型 | 熱縮 |
| 材料 | 聚烯烴 |
| 最低工作溫度 | -55°C |
| 無鹵素 | 是 |
| 阻燃 | 是 |
| 最高工作溫度 | +110°C |
| 角度 | 直向 |
| 收縮比 | 3:1 |
| 套管長度 | 1.2 m |
| 收縮直徑 | 12.7mm |
| 適用區域 | 全球, 全球 |
| 收縮率 | 3:1 |
| Fluid Type | Brake Fluid, Water |
| Shrink Temperature (Min)?(°C) | 70 |
| Recovery Temperature?(°C) | 121 |
| 墻面類型 | 單一 |
| 封裝方法 | 件 |
| Flexibility | Semi-Rigid |
| Resistant To | Abrasion, Fluids, Mechanical Damage, Weathering |
| 低釋氣 | 否 |
| 易燃性 | 滯燃 |
| 流體阻力 | 浸沒式保護, 濕度/噴射保護 |
| 產品來源 | US |
