CR102J5RS215QF6
Switch Rocker ON None OFF SPST Quick Connect Oval Rocker 16A 250VAC
廠商型號:
CR102J5RS215QF6
芯天下內部編號:
54-CR102J5RS215QF6
生產廠商:
c&k components
描述:
Switch Rocker ON None OFF SPST Quick Connect Oval Rocker 16A 250VAC
產品類別:
Switches and Relays|Switches|Rocker Switch
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Switch Configuration | ON None OFF |
| Pole Throw Configuration | SPST |
| Mounting | Panel Mount |
| Maximum Current Rating | 16@125VAC A |
| Maximum AC Voltage Rating | 250 V |
| Terminal Type | Quick Connect |
| Illumination Type | LED |
| Operating Temperature | -20 to 85 °C |
| Standard Package | Bulk |
| Actuator Style | Oval Rocker |
| Electrical Life | 10000 |
| Product Length | 23 |
| EU RoHS | Compliant |
| Maximum Operating Temperature | 85 |
| Product Depth | 23 |
| Product Height | 28.1 |
| Base/Housing Material | N/A/Nylon 6/6 |
| Maximum AC Voltage Rating | 250 |
| Contact Plating | Silver |
| Minimum Operating Temperature | -20 |
| Maximum Current Rating | 16@125VAC |
| Actuator Material | Polycarbonate |
| Unit Pack | 1 |
| MOQ | 1000 |
| Packaging | Bulk |
| Switch Function | On-Off |
| Current Rating | 16A (AC) |
| Mounting Type | Panel Mount, Snap-In |
| Voltage Rating - AC | 125V |
| Electrical Life | 10,000 Cycles |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
| Color - Actuator/Cap | Red |
| Actuator Marking | No Marking |
| Panel Cutout Dimensions | Circular - 20.20mm Dia |
| Illumination Voltage (Nominal) | 1.85 VDC |
| Circuit | SPST |
| Illumination Type, Color | LED, Red |
| rohs | Lead free / RoHS Compliant |
| Factory Pack Quantity | 1 |
| Voltage Rating AC | 250 V |
| Product Category | Rocker Switches |
| Contact Rating | 10 A at 125 V |
| Series | CR |
| Contact Form | SPST |
| Illumination Color | Red |
| Mounting Style | Panel |
| Actuator | Rocker |
| Illumination | Neon |
| RoHS | RoHS Compliant |
| 致動器標志 | No Marking |
| 系列 | CR |
| 顏色 - 致動器/蓋帽 | Red |
| 面板開口尺寸 | Circular - 20.20mm Dia |
| 開關功能 | On-Off |
| 額定電壓 - 交流 | 125V |
| 電路 | SPST |
| 額定電流 | 16A (AC) |
| 照明電壓（標稱值） | 1.85 VDC |
| 致動器樣式 | Round - Illuminated |
| 裝配類型 | Panel Mount, Snap-In |
| 照明類型，顏色 | LED, Red |
